3.0 Thermal Conductivity Silicone Potting Compound For EV Battery Power Supply Industrial Electronics
Product Overview for silicone potting compound:
The 3.0 Thermal Conductivity Silicone Potting Compound is a highly thermally conductive, two-component, addition-curing silicone rubber material. It achieves a thermal conductivity of 3.0 W/m·K by incorporating a high-density filling of highly conductive powders—such as aluminum oxide and aluminum nitride—within a silicone matrix. It combines the inherent flexibility and insulating properties of silicone with exceptional heat dissipation capabilities.
Technical Parameters for silicone potting compound:
Exterior:grey liquid
viscosity:11000±2000mpa's
hardness:45-50shore A
thermal conducitivity:3.0(W/M▪K)
Flame retardant rating (V) (UL94):V-0
Wide temperature range (-40℃-150℃)
Product Applications for silicone potting compound:
New Energy Vehicles (EVs): On-Board Chargers (OBC), Battery Management Systems (BMS), DC-DC Converters. Power Supplies: High-Power LED Drivers, Inverters, 5G Communication Base Station Power Supplies. Industrial Electronics: Variable Frequency Drives (VFDs), Servo Drives, High-Voltage Transformers.
After sale service about silicone potting compound:
After sales Service
1. Provide complete product technical information;
2. Debug the product formula according to customer requirements to meet customer
requirements for certain special properties of the product;
3. Our company welcomes users to cooperate, communicate and discuss solutions with our
engineers.
